GTLD Platform Lift
The Ganser GTLD platform stairlift represents the ultimate technical upgrade for ensuring accessibility in spaces with unique architectural challenges. It is specially designed for buildings with narrow, confined, or heavily frequented staircases, where every centimeter of free space counts.
The defining feature of the Ganser GTLD lies in its intelligent rearward parking position and its extended travel angle of -10° to +47°. When negatively inclined, the lift parks comfortably on the upper platform without restricting the stairs, leaving the passage entirely clear and safe for pedestrian traffic, without affecting the building's functionality.
Manufacturer: GANSER
Description
Ganser GTLD: The platform stairlift for ultimate space-saving
Key Advantages
Maximum freedom of movement: Ideal for narrow hallways and high-traffic entrances thanks to its intelligent rearward parking position.
Flexibility on demanding routes: With an extended travel angle of -10° to +47°, it can handle even the most challenging architectural obstacles.
Enhanced stability: Equipped with a stainless steel rail and a double rack and pinion drive, offering completely smooth and quiet travel.
Modern aesthetics: The platform and access ramps feature an anti-slip surface in the premium RAL 7016 shade, perfectly harmonizing the system with modern architecture.
Technical Specifications
Safe and robust: The durable stainless steel rail guarantees long-lasting operation and can also be used as a handrai
Payload: 300 kg
Gradient: -10° to +47°
Speed: 0.12 m/s
Drive: Double toothed racks
Operation: Battery
Platform size: Standard 800 x 1,000 mm (variable sizes available on request)
Color Recommendation: Premium combination of RAL 7016 and RAL 7048
Country of Manufacture: Austria
Safety and Functionality Equipment
Easy-to-understand information and status diagnostics display
Control unit with soft-touch push buttons for up/down movement
Emergency stop button and integrated emergency call button
Wireless wall switch with a key switch (available in surface-mounted or flush-mounted versions)
Optional feature for a fully motorized, automatic access ramp
