GTLE
High-quality materials, ergonomic softtouch control buttons, the informative display and the elegant grab rail guarantee a comfortable trip up and down and blend first-rate protection with a perfect design. Whether it’s installed indoors or outdoors, the new GTLE delivers what it promises, even in harsh climatic conditions.
Protective and comfort. Because the security of our customers is our main priori ty, the anti-rolling mechanism, the contact data and the side shift mechanism all meet current security standards.
Description
GTLE
Narrow staircases or complex spiral staircases are no challenge for the new GTLE. Thanks to its new, space-saving, innovative design, our all-rounder offers a higher payload with a larger platform and maximum safety in the familiar quality. With its simple operation and many clever functions, our all-rounder overcomes every barrier and takes you effortlessly to your destination. The individual application options and the almost silent, solid drive concept of the new GTLE is a novelty in its class
GTL30
Complex spiral staircases and winding ascents and descents are no problem for our GTL30. These platform stairlifts have been specially developed for curved routes and stairs with changes in incline. With the help of this stairlift, almost any flight of stairs can be reproduced – so nothing stands in the way of accessibility. The dual drive system used for this lift is unique on the market, as it allows the lift to ascend and descend in one runway and does not require a stabilizing tube
Product Comparison
| Gradient | Payload | Speed | Drive | Operation | Platform size | Color recommendation | |
|---|---|---|---|---|---|---|---|
| GTLE | 0° bis +50° | 300 kg | 0,12 m/s | Toothed racks | Battery | Standard 800 x 1,000 mm, variable sizes on request | RAL 7016, 7048 |
| GTL30 | -60° to +60° | 300 kg | 0,10 m/s | Double toothed racks | Battery | Standard 800 x 1,000 mm, variable sizes on request | RAL 7040 |
100% built in Austria
Thanks to top-quality materials, innovative technology, an attractive design and an uncompromising commitment to flexibility, we guarantee the best possible comfort and reliable safety for all our products.
- Informative display with voice output makes things easier to understand
- Operating unit
- Up and Down soft-touch control buttons
- Emergency stop buttons
- 2 emergency call buttons
- Wireless wall switch (surface-mounted or flushmounted) with key-operated switch
- Chassis in RAL7016 and RAL7048 (standard colour)
- Platform with non-slip surface in RAL7016
- Ramps with non-slip surface in RAL7016
- Roll-off guard, optionally available with 3rd ramp
- Stainless steel rail; top part can be used as a handrail
Stainless steel rail
Safe and sturdy: the resistant stainless steel rail
guarantees durable functionality and can also be used as a handrail.
Variable platform dimensions
Optimum use of space and maximised platform thanks to millimetre-precise adjustment.
From the special colours available for the coating to the ability to adapt the lift to the building’s structure, our lift systems are individually made and fitted by our in-house technicians – ensuring they look good and provide top quality in line with your exact wishes.
High-quality materials, ergonomic softtouch control buttons, the informative display and the elegant grab rail guarantee a comfortable trip up and down and blend first-rate protection with a perfect design. Whether it’s installed indoors or outdoors, the new GTLE delivers what it promises, even in harsh climatic conditions.
The compact and sturdy chassis is located 240 mm from the wall with the platform folded up and provides more space, particularly on narrow staircases.
Landings can be safely passed using curves (Fig. 2) or by changing the inclination (Fig. 1). The rail is attached directly to the wall or to supports (Fig. 1 & 2). Multiple stopping points and parking positions can be individually planned.
Optional third ramp
Ideal for when there is little space for accessing the platform from the opposite side of the lift.
High quality materials
Weatherproof and robust:
Components of stainless steel and metal enable a smooth and safe ride as well as ensure personal safety and a visually pleasing product.
Control operated ergonomics
Simple and intuitive:
Touch surface control buttons, which are also in braille, can be used for an almost effortless performance.
Informative display
Time and cost saving:
By looking at this display all the necessary informati on is given at a glance, for example, when main tenance procedures are due or when the status operation changes.
Stainless steel rail
Safety and stability:
The resistant stainless steel guarantees a durable functionality and can also be used as a handrail.
Twin drive
No stabilization rail is necessary:
The unique twin drive makes an ascent and descent without a third rail possible. This is cost-saving in its production and offers a maximum of stability during the ride.
Fully automated safety device
Protective and comfort:
Because the security of our customers is our main priori ty, the anti-rolling mechanism, the contact data and the side shift mechanism all meet current security standards.
Surface – mounted wireless wall switch
Permanently mounted and lockable, perfect for public areas or outdoor facilities.
Flush – mounted wireless wall switch
The ideal wireless wall switch for incorporating into existing switch installations.
Hand – held remote control
Hand – held remote control
