Description
CERTIFICATIONS & PATENT
Regulation EU 2017/745 Medical Devices – class 1
Directive 2006/42/EC – Machinery Directive
Directive 2004/108/EC – EMC Electromagnetic Compatibility
TECHNICAL DETAILS
Maximum capacity: 140 kg
Maximum travel: 1350 mm
Depth of seat inside the water: 850 mm
Time of lowering – lifting with weight into water: 45 sec
Weight of the lift: 60 kg
Battery: 24 V
OPTIONAL
4-point safety belt
5-point safety belt
Cover
TECHNICAL FEATURES
IPX06 mobile push-button panel with spiral cable
Up – down controls
Headrest included
Folding seat to reduce the overall dimensions of the lift
Removable telescopic leg support
Adjustable armrests
2-point ventral safety belt
Emergency stop button
Removable battery tor charging
External battery charger
Average autonomy: 50 working cycles
Galvanizing and 180°C powder coating treatment
Stainless steel frame for in-water parts
Access to water projects from Bibikas Special
Additional information
| Μέγιστη χωρητικότητα | |
|---|---|
| Μέγιστη διαδρομή | |
| Βάθος του καθίσματος μέσα στο νερό | |
| Χρόνος καθέλκυσης – ανύψωσης με το βάρος στο νερό | |
| Βάρος του ανελκυστήρα | |
| Battery | 24 V |
